Description:
The MSI MAG PANO 100R PZ White Edition is engineered for builders seeking a sleek, modern aesthetic combined with advanced functionality. Its 270° panoramic tempered glass panels provide an unobstructed view of your components, making it perfect for showcasing your build. Designed with back-connect motherboard support, it ensures a clutter-free interior by routing cables behind the motherboard tray. The case comes equipped with three 120mm ARGB reverse-blade intake fans and one 120mm ARGB exhaust fan, delivering efficient airflow and vibrant lighting. With support for up to three 360mm radiators and vertical GPU installation, the MAG PANO 100R PZ offers versatility for both air and liquid cooling setups.

Key Features:

• 270° panoramic tempered glass front and side panels

• Supports ATX, Micro-ATX, and Mini-ITX motherboards

• Back-connect motherboard compatibility for improved cable management

• Pre-installed with 3x 120mm ARGB reverse-blade intake fans and 1x 120mm ARGB exhaust fan

• Supports up to 10 fans and three 360mm radiators simultaneously

• Vertical GPU support with included adjustable GPU holder

• Dual-chamber design with 90mm cable routing space

• Tool-less panels for easy access and maintenance

• Magnetic dust filters on top and bottom for easy cleaning

• Front I/O includes USB 3.2 Gen 2×2 Type-C, USB 3.2 Gen 1 Type-A, and 3.5mm audio jack

Specifications:

• Motherboard Support: ATX, Micro-ATX, Mini-ITX

• Case Type: Mid-Tower

• Dimensions (D x W x H): 518.7 x 290 x 482 mm

• Weight: Approximately 14.5 kg

• Expansion Slots: 8 horizontal, 4 vertical

• Drive Bays: Up to 5x 2.5″ SSDs and 2x 3.5″ HDDs

• Maximum GPU Length: 400mm

• Maximum CPU Cooler Height: 166mm

• Maximum PSU Length: 200mm

• Radiator Support:

  • Top: Up to 360mm

  • Side: Up to 360mm

  • Bottom: Up to 360mm

• Fan Support:

  • Top: 3x 120mm or 2x 140mm

  • Side: 3x 120mm

  • Bottom: 3x 120mm or 2x 140mm

  • Rear: 1x 120mm

• Pre-installed Fans: 3x 120mm ARGB reverse-blade intake fans (side), 1x 120mm ARGB exhaust fan (rear)

• Front I/O Ports:

  • 1x USB 3.2 Gen 2×2 Type-C

  • 1x USB 3.2 Gen 1 Type-A

  • 1x 3.5mm combo audio jack

• Cable Management: 90mm routing space with integrated Velcro straps

• Dust Filters: Magnetic filters on top and bottom
