Description :
The GIGABYTE B860M GAMING X WIFI6E motherboard is engineered to support Intel Core Ultra Series 2 processors on the LGA 1851 socket, delivering exceptional performance for gaming and professional applications. With a 8+1+2 phase digital VRM design utilizing 60A DrMOS, it ensures stable and efficient power delivery.

This motherboard supports up to 128GB of DDR5 memory with speeds up to 9200 MHz (OC), providing ample bandwidth for demanding tasks. It features two M.2 slots, including one PCIe 5.0 x4 and one PCIe 4.0 x4, offering versatile and high-speed storage options. The inclusion of Wi-Fi 6E and 2.5GbE LAN ensures fast and reliable networking capabilities.

Designed with user convenience in mind, the B860M GAMING X WIFI6E includes EZ-Latch Plus for tool-free installation of M.2 drives and graphics cards, as well as a Q-Flash Plus button for easy BIOS updates. Its advanced thermal design, featuring VRM Thermal Armor and M.2 Thermal Guards, maintains optimal temperatures under heavy workloads.

Key Features:

• Supports Intel Core Ultra Series 2 processors (LGA 1851 socket)

• 8+1+2 phase digital VRM design with 60A DrMOS

• Dual channel DDR5 memory support, up to 128GB, 9200 MHz (OC)

• Two M.2 slots (1 x PCIe 5.0 x4, 1 x PCIe 4.0 x4) with Thermal Guards

• Realtek 2.5GbE LAN and Wi-Fi 6E for high-speed networking

• USB4 Type-C port with DisplayPort Alternate Mode

• EZ-Latch Plus for tool-free M.2 and PCIe installation

• Advanced thermal design with VRM Thermal Armor and M.2 Thermal Guards

• Realtek ALC897 audio codec with high-definition audio support

• RGB Fusion 2.0 with multiple RGB headers for customization

Key Specifications:

• Form Factor: Micro-ATX

• Chipset: Intel B860

• CPU Socket: LGA 1851

• Memory: 2 x DDR5 DIMM slots, up to 128GB, 9200 MHz (OC)

• Storage Interface: 2 x M.2 slots (1 x PCIe 5.0 x4, 1 x PCIe 4.0 x4), 4 x SATA 6Gb/s

• Graphics Output: 1 x HDMI 2.1, 1 x DisplayPort 2.1

• Expansion Slots: 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x4

• Audio: Realtek ALC897 codec, 7.1-channel HD audio

• LAN: Realtek 2.5GbE LAN

• Wireless: Wi-Fi 6E (802.11ax), Bluetooth 5.3

• USB Ports: 1 x USB4 Type-C, multiple USB 3.2 Gen2 and Gen1 Type-A ports, 4 x USB 2.0

• BIOS: 256 Mbit UEFI AMI BIOS
